| Electronic control on joystick | Air condition | |
| Hydraulic Line(per one more) | LED lights | |
| Rear Video Camera | Varta Anti-Freeze Battery | |
| Whole drive system | Hydraulic system(torque converter) | |
| Overall weight(kg) | 4000 | |
| L×W×H(mm) | 5476×1735×2537 | |
| Rated bucket capacity(m3) | 0.8-0.9 | |
| Rated load(kg) | 1600 | |
| Specification | Dump height (mm) | 2180 |
| Dump distance(mm) | 510 | |
| Wheelbase(mm) | 1500 | |
| Thread(mm) | 2280 | |
| Total time(s) | 8 | |
| Engine | Model | CHANGCHAI490 |
| Type | Direct injection, Horizontal, Water-cooled, Four stroke | |
| Rated power(KW) | 36.8 | |
| Rated speed(r/min) | 2400 | |
| Working system | Gearbox type | ZL-10 |
| Walking pump | ZK-240 | |
| Working pump (Double Pump) | CBQL-F532 | |
| Steering system | Max. turning angle | 45 |
| Min turning radius(mm) | 3600 | |
| Hydraulic system | Working pressure | 16Mpa |
| Boom lifting time | 4.8S | |
| Tank capacity | 45L | |
| Tires | Standard tires | 20.5-16 |
| Stand bucket | Width (mm) | 1800 |
Earthmoving Equipment
HARMAC
1.6 Ton Telescopic Loader
Model: LT16
A Telescopic loader is a multi-purpose material handling machine equipped with an extendable boom that allows operators to lift, load, and transport materials at varying heights and distances. Combining the capabilities of a wheel loader and a telescopic handler, it provides enhanced reach and flexibility for demanding work environments.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
