| Model | STS04 | STS06 | STS08 | STS10 | STS12 |
| Operating weight(KG) | 40000 | 5800 | 7850 | 9600 | 11950 |
| Static line load(N/CM) | 125 | 165 | 225 | 225 | 310 |
| SIZE(MM)L*W*H | 4040*1430*2520 | 4550*1760*2725 | 4820*1765*2645 | 5065*2020*2720 | 5920*2260*2950 |
| Drum width(MM) | 1300 | 1500 | 1600 | 1800 | 2100 |
| Drum diameter(MM) | 1000 | 1150 | 1200 | 1250 | 1500 |
| output power(KW) | 36/34.5/33.6 | 68/54.1 | 74/68 | 74 | 93 |
| Rotational speed(rpm) | 2400/3000/2400 | / | 2200/2400 | 2200 | 2200 |
| Electrical equipment(V) | 12 | 24 | 24 | 24 | 24 |
| Speed(KM/H) | 0-7.5 | 0-9 | 0-9.5 | 0-10 | 0-10 |
| Theoretical climbing ability | 30% | 30% | 30% | 30% | 30% |
| Vibration frequency(HZ) | 54 | 45 | 52 | 50 | 28/32 |
| Vibration amplitude(MM) | 0.5 | 0.5 | 0.5 | 0.5 | 1.7/0.8 |
| Excitation force(KN) | 70 | 85 | 118 | 150 | 260/160 |
| Lubricating oil(L) | 12 | 12 | 15 | 15 | / |
| Hydraulic oil(L) | 63 | 115 | 120 | 125 | 135 |
| Fuel capacity(L) | 76 | 95 | 140 | 154 | 165 |
Road Construction Equipment
HARMAC
10-ton STS10 Road Roller
Model: STS10
Road Roller is a compaction machine used to compress soil, asphalt, or gravel surfaces to increase density and stability.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
