| Specifications | Rated operating capacity(kg) | 1100 |
| Tipping load(kg) | 2200 | |
| Bucket capacity(m3) | 0.45 | |
| Operating weight(kg) | 3180 | |
| Maximum Breakout Force | 24 | |
| Maximum Traction Force | 25 | |
| Diesel Tank | 78L | |
| Hydraulic Tank | 45L | |
| Tires | 10/16.5 | |
| Dimensions | Max. Operation Height | 3890mm |
| Cab Roof Height | 2000mm | |
| Departure Angle | 21° | |
| Ground Clearance | 185mm | |
| Wheelbase | 1078mm | |
| Overall Length (without attachments) | 2825mm | |
| Overall Length (with standard bucket) | 3410mm | |
| Bucket Ground Level Angle | 30° | |
| Dump Height | 2475mm | |
| Lift Height (at pin) | 3120mm | |
| Dump Reach | 465mm | |
| Dump Angle | 43° | |
| Bucket Rotation Angle at Max Height | 99° | |
| Overall Width (with standard bucket) | 1800mm | |
| Turning Radius | 1213mm | |
| Overall Width (without bucket) | 1640mm | |
| Track Width | 1370mm | |
| Engine | Brand and Model | Xinchai A498BG |
| Type | Inline Four-Cylinder Turbocharged | |
| Engine Rated Power | 45KW | |
| Engine Rated Speed | 2500r/min | |
| Hydraulic system | Brand | PWG(Italy) |
| Standard Auxiliary Flow | 80liters/min | |
| High Auxiliary Flow | 130liters/min | |
| Hydraulic Pressure | 21Mpa | |
| Sum of three terms | ≤10s | |
| Travel system | Brand | PWG(Italy) |
| Max. travel speed (low range-standard) | 14km/h | |
| Max.Torque | 2290Nm |
Earthmoving Equipment
HARMAC
1100KG Crawler Mini Skid Steer Loader
Model: SM1100
A Crawler Mini Skid Steer Loader is a compact, multi-purpose loader equipped with rubber tracks instead of wheels, designed for material handling and light construction work in confined or difficult terrain environments. Combining small size with strong maneuverability, it delivers the functionality of a traditional skid steer in a more compact and flexible form.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
