| Model | AL131 |
| Type | long hand bar type |
| Dimension of Tractor | L: 2960mm W(adjustable):1050/1200mm H: 1220mm |
| Engine pulley diameter(standard) | 140mm(5.5”) |
| Transmission pulley diameter(standard) | 180mm(7”) |
| Rubber wheel size | 7.50-16 |
| Cage wheel diameter | 800mm |
| Towing pin diameter | 26mm |
| V-belt | Length: 1880mm(74”) Qty.:2pcs |
| Brake system | Small-scale braking |
| Clutch type | Dry multiple disc clutch |
| Lubricating Oil | SAE90 |
| Lubricating Oil Capacity | 5.5-6L |
| Tractor max. speed | 23.5km/h |
| Transmission ratio | Low speed 1st Gear: 44:1 |
| Mid speed 2nd Gear: 23:1 | |
| High speed 3rd Gear: 8:1 | |
| Reverse Gear: 56:1 | |
| Tractor Weight(without engine) | 210kg |
| diesels engine max.output | 14Hp |
Agricultrual Equipment
HARMAC
14HP Walking Tractor
Model: AL131
A walking tractor, also known as a two-wheeled tractor or garden tractor, is a compact, walk-behind agricultural vehicle designed for small-scale farming and gardening tasks. It is typically used for tasks like plowing, tilling, planting, and hauling in smaller or more confined agricultural areas.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
