ITEM	UNIT	PARAMETER
Vehicle		Garbage compactor truck
Overall dimensions	mm	7300×2350×2750
Tank volume	m3	6
GVW	kg	Appro×8495
Curb weight		Appro×6195
Payload		Appro×2300
Wheel base	mm	3800
Suspension		1210/2490
F/R track base		1770/1586
Approach/departure angle	°	24/14
Max speed	km/h	95
Axle Load	kg	2950/5300
Tire specification	7.50-16 / 7 Units	Number of axles	2
Engine model	CY4102-C3C	Diesel, 4 Cylinder, direct line, water cooling
Engine performance	ml/kw	3856/100
Steering	Power	Transmission		5F&1R
Cab passenger	3	Electric System		24V
Tank material		Carbon steel
Standard configuration	1. Hydraulic system powered by trucks chassis PTO

	2. Body with rear lifting system to handle garbage containers capacity 660 L and 1100 L

	3. Body sides and roof built from high tensile sheets thickness 3 mm.

	4. Box platform built with high tensile sheets thickness 5 mm, hopper floor built with high tensile sheets thickness 6 mm.

	5. Body painted 1 coat anti-corrosion primer and 2 coats synthetic paint

	6. Rear tailgate full -floating design water tight with hopper capacity 1.35 m3
