| RTX15-10 | Overall Dimension: | 6800x1900x2960mm |
| Rated load: | 1500kgs | |
| Operate weight: | 4200kgs | |
| Bucket width: | 1700mm | |
| Bucket capacity: | 0.7m³ | |
| Dig bucket capacity | 0.1m³ | |
| Max. dumping height | 2900mm | |
| Max. digging depth | 2000mm | |
| Dumping distance | 1050mm | |
| Engine | Model: | YUNNEI engine |
| Rated power | 37KW | |
| Pattern: | In-line, water-cooling, 4 cylinder, direct inject | |
| Optional model: | XINCHAI/YANMAR engine | |
| Storage Battery | 80 A free-maintenance | |
| Transmission System | Gearbox model: | Mechanical or hydraulic |
| Axle: | import brand drive axle(drum brake) | |
| Drive model: | Four wheel drive | |
| Steering System | Steering angle | ±35° |
| Min. Turning Radius: | 4500mm | |
| Pattern: | Articulated type full-hydraulic power steering | |
| Service brake | Drum brake(Expanding shoe brakes) | |
| Parking brake: | Hand operate,disc brake | |
| Tyre | Model: | 20.5-16 |
Backhoe Loader
HARMAC
1500KG Backhoe Loader
Model: RTX15-10
A Backhoe Loader is a versatile construction machine that combines a front loader bucket and a rear backhoe excavator on a single chassis, allowing it to perform both loading and digging operations efficiently. Designed for multi-purpose use, it is widely recognized as one of the most practical and cost-effective machines for small to medium construction projects.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
