Model			S07	S08	S10	V10	S12	T08	T10	T12
(50%)Rate load			890	955	1100	1100	1260	955	1100	1360
Tipping load			1780	1910	2200	≥2200	2520	2729	3143	3886
Rated working load			2950	3210	3550	4000±3%	4000	4100	4750	5150
Maximum breakout force			24kN	24kN	25kN	≥30	30kN	23 kN	28.5kN	33kN
Maximum traction force			25kN	25kN	30kN	≥32	32kN	32 kN	35kN	43kN
Maximum lifting force			2450	1910	2200	≥25	2400	2500	3765	2800
Engine		Engine	Yanmar/Yuchai	Yanmar/Yuchai	Yanmar/Yuchai	Yanmar/Yuchai	Yanmar/Yuchai	Yanmar/Yuchai	Yanmar/Yuchai	Yanmar/Yuchai
		Rated power	50.2kW/36.5kW	49.9kW/50.2kW/55.8kW	61.3kW/66kW	53.7	73.5kW/61.3kW/53.7kW	49.9kW	53.7 kW	53.7kW
		Rated speed	2400rpm	2400rpm	2500rpm/2400rpm	2500	2400rpm	2400rpm	2500rpm	2500rpm
		Emission	EPA T4F/EU stage V/China III
		displacement	3.319L/2.982L	3.319L	3.319L/3.621L	3.319(	3.3L	3.319L	3.319L	3.319L
		Peak Torque	238N.m/190N.m	241N.m/238.8N.m/255N.m	293.5N.m/350N.m	269~291/1625±25	286.6N.m	241N.m	291N.m	291N.m
		Cooling type	water cooling	water cooling	water cooling	water cooling	water cooling	water cooling	water cooling	water cooling
Performance Parameter		Operation type	Pilot Hydraulic Control/Pilot hydraulic control&multifunctional electronic control /Electro-hydraulic Proportional Control
		Low shift speed	14km/h	km/h	12km/h	12-16.5-12PR	11km/h	9km/h	9km/h	8km/h
		Max Speed	14km/h	14km/h	21km/h	19±5%	19km/h	14km/h	14km/h	14km/h
Hydraulic system		Standard Flow	79L/min	79L/min	95L/min	80	95L/min	79L/min	80L/min	95L/min
		High Flow	L/min	120L/min	142.5L/min	120	142.5L/min	120L/min	120L/min	142.5L/min
		Pressure	210bar	210bar	210bar	210±10	210bar	230bar	230bar	230bar
		Cycle time	10S	10S	10S	≤11	13S	10s	14S	11S
Electric system		Voltage	12V	12V	12V	12V	12V	12V	12V	12V
Electric system		Battery Capacity	93Ah	93Ah	93Ah	93Ah	93Ah	93Ah	95Ah	95Ah
Outline parameters	A	Max operation height	3800mm	3800mm	4080mm	4198±50	4086mm	3788 mm	4188mm	4160mm
	B	Hinge pin height	3020mm	3020mm	3210mm	3220±50	3235mm	3003mm	3214mm	3300mm
	C	Cab height	1960mm	1960mm	2040mm	2040±50	2040mm	2053mm	2088mm	2100mm
	D	Bucket bottom max height	2865mm	2865mm	3035mm	3050±50	3065mm	2830mm	3047mm	3135mm
	E	Length without bucket	2703mm	2703mm	2930mm	2994±50	3010mm	2840mm	2880mm	2915mm
	F	Length with bucket	3410mm	3410mm	3805mm	3965±100	3800mm	3520mm	3851mm	3786mm
	G	Maximum bucket dump angle	40°	40°	40°	48±2	40°	31°	40°	40°
	H	Dumping height (Max dump angle)	2400mm	2400mm	2530mm	2395±50	2520mm	2454mm	2461mm	2615mm
	K	Rollback angle at ground	32°	32°	30°	30±2	30°	28°	29.1°	26°
	L	Bucket rollback angle Max height	101°	101°	107°	91.5±2	83°	96°	91.5°	84°
	J	Dumping reach (Max dunp angle)	550mm	550mm	600mm	930±50	1000mm	682mm	1059mm	1025mm
	M	wheelbase	1079mm	1079mm	1313mm	1320±2%	1320mm	1478mm	1498mm	1640mm
	O	Departure angle	22°	22°	25°	25±1	25°	23°	25.5°	31°
	P	Ground Clearance	185mm	185mm	205mm	205±2%	205mm	205mm	215mm	216mm
	R	()Front Turning radius(no bucket)	1212mm	1212mm	1375mm	1443±50	1450mm	1307 mm	1348mm	1468mm
	S	()Front Turning radius(no bucket)	1952mm	1952mm	2264mm	2405±50	2300mm	2011mm	2336mm	2293mm
	T	Rear turning radius	1792mm	1792mm	1816mm	1806±50	1840mm	1605mm	1829mm	1806mm
	U	Rear length	1162mm	1162mm	1175mm	1060±50	1175mm	970mm	972mm	885mm
	V	wheel track	1370mm	1370mm	1500mm	1500±2%	1500mm	1485mm	1496mm	1595mm
	W	Tire edge width	1640mm	1640mm	1800mm	1800±50	1800mm	1805mm	1896mm	2045mm
	X	Max Width(bucket)	1800mm	1800mm	2000mm	2000±10	2000mm	1800mm	2000mm	2130mm
Others	/	Bucket capacity (heap)	0.45m³	0.5m³	0.6m³	0.6	0.6m³	0.45m³	0.6m³	0.6m³
	/	Bucket capacity	0.4m³	0.45m³	0.47m³		0.48m³	0.5m³	0.47m³	0.47m³
	/	Fuel Tank	78L	78L	105L	105	105L	78L	105L	100L
	/	Hydraulic tank	45L	45L	50L	50	50L	45L

Earthmoving Equipment XCMG

2000KG Skid Steer Loader

Model: XC7-SR07B

A Skid Steer Loader is a compact and highly maneuverable construction machine designed for material handling, loading, and multi-purpose job site operations. Featuring a rigid frame and skid-steering system, the machine turns by varying the speed of its left and right wheels or tracks, allowing zero-radius turning and excellent performance in confined spaces.

Brand

XCMG

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
