| Description | Backward tipping sidewall semi trailer |
| Dimension(mm) | 9000-105000*2550*2800-3300 |
| Vehicle Weight | 8.8T-15T(Hydraulic oil and accessories included) |
| Loading Capacity | 40-80T |
| King Pin | 2″(50mm)/3.5″(90mm) |
| Axle | 4*13T HUIZHOU FUWA Axles |
| Tire | Vacuum tire 12.00R20 |
| Main Beam Spec | T700 Steel, Height:500mm, Plate Thickness:10-18mm |
| Side wall thickness | 5-6mm |
| Bottom plate thicknes | 6-8mm |
| Landing Gear | Sing side operation,heavy duty |
| Suspension System | Mechanical suspension |
| Steel leaf spring | 16mm*120*10PCS |
| Braking System | Dual line pneumatic brake,with hose and connector |
| ABS | Optional |
| Electronic System | Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light |
| Painting | Complete chassis sand blasting to clean rust, 1coat of Environmentally anticorrosive prime, then 2 Topcoats, at last temperature baking varnish. |
| MOQ | 1 Unit |
