| Description | Backward tipping sidewall semi trailer |
| Dimension(mm) | 9000-105000*2550*2800-3300 |
| Vehicle Weight | 8.8T-15T(Hydraulic oil and accessories included) |
| Loading Capacity | 40-80T |
| King Pin | 2″(50mm)/3.5″(90mm) |
| Axle | 4*13T HUIZHOU FUWA Axles |
| Tire | Vacuum tire 12.00R20 |
| Main Beam Spec | T700 Steel, Height:500mm, Plate Thickness:10-18mm |
| Side wall thickness | 5-6mm |
| Bottom plate thicknes | 6-8mm |
| Landing Gear | Sing side operation,heavy duty |
| Suspension System | Mechanical suspension |
| Steel leaf spring | 16mm*120*10PCS |
| Braking System | Dual line pneumatic brake,with hose and connector |
| ABS | Optional |
| Electronic System | Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light |
| Painting | Complete chassis sand blasting to clean rust, 1coat of Environmentally anticorrosive prime, then 2 Topcoats, at last temperature baking varnish. |
| MOQ | 1 Unit |
Trailer
HARMAC
4 Axle Rear Dump Trailer
Model: 80TON
A trailer is a non-powered vehicle designed to be towed by a truck or tractor. It is used to carry goods, equipment, or materials and comes in various types depending on the cargo. Trailers are essential in transportation for moving large or heavy loads efficiently.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
