| Product Type | DR-160 |
| Chassis length(mm) | 5100 |
| Track width(mm) | 6700 |
| Overall height(M) | 3.95 |
| Machine weight(t) | 36 |
| Maximum drilling depth(M) | 45 |
| Drilling diameter(mm) | 600-1800 |
| Engine rated power(KW/rpm) | 191KW |
| Maximum torque of power head(N.m) | 160000(optionl) |
| Power head speed rpm | 50-70 |
| Power head can be customized | YES |
| Drill mast | ±5 |
| Pitch angle | 5 |
| Maximum travel speed of chassis(KM/h) | 4 |
| Maximum creep degree of chassis | 30 |
| Maximum travel torque(N.m) | 61000 |
| Working state width(mm) | 3300 |
| Transport status width(mm) | 3000 |
| Transport status height(mm) | 3950 |
Drilling Equipment
HARMAC
45M Rotary Drilling Rig Machine DR160
Model: DR160
Rotary Drilling Rig is a foundation construction machine used for drilling deep holes for pile foundations. It is widely applied in building, bridge, and infrastructure projects, offering high efficiency, stability, and precise drilling performance.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
