| Engine Brand | Yanmar 380 | Maximum Load (kg) | 480 |
| Rated Power (HP) | 20–25 HP | Maximum Breakout Force (kN) | 450 |
| Rated Speed (rpm) | 2500–3000 | Bucket Capacity (m³) | 0.12 |
| Number of Cylinders | 3 | Travel Speed (km/h) | 0-6 |
| Intake Method | Natural aspiration | Working Cycle Time (s) | 9 |
| Displacement (cc) | 639 | System Pressure (bar) | 17-21 |
| Emission Standard | EPA | Fuel Tank Capacity (L) | 13 |
| Rated Load (kg) | 350 | Operating Weight (kg) | 1200 |
| Structural Dimensions | |||
| Item | Parameter | Item | Parameter |
| Maximum Operating Height | 2450mm | Height to Bucket Hinge Pin | 1870mm |
| Overall Height | 1350mm | Maximum Bucket Level Height | 1810 mm |
| Overall Length (without attachment) | 1680mm | Overall Length (with standard bucket) | 2206 mm |
| Maximum Dump Angle at Max Height | 34° | Dump Height | 1510mm |
| Dump Reach | 450mm | Bucket Rollback Angle on Ground | 27° |
| Bucket Dump Angle at Max Height | 114° | Wheelbase | 850mm |
| Ground Clearance | 150mm | Rear Overhang Length | 280mm |
| Wheel Track (standard tires) | 720mm | Machine Width (standard tires) | 1000mm |
| Tire Model | 18*72 | Bucket Width | 1000mm |
Earthmoving Equipment
HARMAC
480KG Crawler Mini Skid Steer Loader
Model: SM480
A Crawler Mini Skid Steer Loader is a compact, multi-purpose loader equipped with rubber tracks instead of wheels, designed for material handling and light construction work in confined or difficult terrain environments. Combining small size with strong maneuverability, it delivers the functionality of a traditional skid steer in a more compact and flexible form.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
