Overall dimension	Approx.960025503250mm
GVW	Approx.18000kg
Curb weight	Approx.10500kg
Chassis brand	DF
Traction type	4*2, left or right hand drive
Chassis Description
Chassis model	EQ1185L
Wheelbase	5600mm
Tire specification	295/80R22.5
Tire quantity	6+1 units
Engine	Engine model	B6.2NS6B230
	Emission level	Euro 2
	Displacement/output	6200ml/169kw
	Horse power	230hp
Gear box	Number of gears	6 forward gears& 1 reverse
Brake system	Full air brake system, split pneumatic circuit; parking spring brake acting on rear axles, exhaust brake
Axle	Front	6.5T
	Rear	11.5T, ratio 6.33
Suspension	Front	multi pieces Leaf spring
	Rear	multi pieces Leaf spring
Fuel tanker	Type	Iron fuel tank, with lockable cap
Up-part description
Cubage	17cbm
Control system	Electrically Controlled Hydraulic + Hand Hydraulic
Compactor type	Two-way, push in the front, compressor in the back
Standard equipment	Equipped with garbage tanker, push shovel, hydraulic transmission system, electrical controlling system.
