| Model | JC3 | |
| Curb Weight (kg) | 5335 | |
| Rated Volume (m³) | 3 | |
| Dimensions (L×W×H) (mm) | 6700 × 2150 × 2500 | |
| Wheelbase (mm) | 3400 | |
| Front Track (mm) | 1640 | |
| Rear Track (mm) | 1550 | |
| Ground Clearance (Full Load, mm) ≥ | 160 | |
| Gradeability (°) | 14 | |
| Gear Speeds (km/h) | One Gear: | 8 |
| Two Gear: | 14 | |
| Three Gear: | 25 | |
| R Gear: | 8.5 | |
| Turning Radius (mm) ≥ | Inner: 4800, Outer: 8250 | |
| Traction Force (kN) | 32 | |
| Drive Type | Rear-wheel drive | |
| Fuel Tank Capacity (L) | 90 | |
| Explosion-Proof Diesel Engine Model | WH4105DZLDFB | |
| Engine Power (kW) | 56 | |
| Engine Rated Speed (r/min) | 2200 | |
| Protection Type | Explosion-proof electronic protection | |
| Approach Angle (°) | 25 | |
| Departure Angle (°) | 18 | |
| Rear Overhang (mm) | 2170 | |
Concrete Mixer Truck
DONGFENG
DEONGFENG Concrete Mixer Truck
Model: JC3
A concrete mixer truck is a vehicle used to transport and mix concrete. It has a rotating drum that keeps the concrete in liquid form during transit and delivers it ready for construction use. It is widely used in building, road, and infrastructure projects.
Brand
DONGFENG
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
