Condition	New
Chassis model	Dongfeng brand
Drive type	4×2 Left-hand drive
Wheel base	4700mm
driving cab	One and a half rows, 3 seats, flip, power steering, air conditioning
Overall dimension (LWH)	9000×2550×3600
Total mass	18000kg
Curb weight	10500kg
Rated payload weith	7500kg
Engine model	ISB210 30
Engine make	CUMMINS
Rated power	210HP/155KW
Emission standard	Euro 3
Engine type	Diesel engine, 6-cylinders, in line, Six stroke, turbocharged watercooling
Gear box	Big 10 speed Yanshida gearbox, 10JS120
Front axle	5.5-Ton
Rear axle	13-Ton
Tire type	10.00R20, 6 pcs +1pc of spare tire
Steering gear	Power steering
Brake	Air brake
Body Parameter
Capacity	16 CBM
Material	High strength manganese steel
Design	Whole unit with Leakage Proof Design
Ways of Loading	Rear Loading with optional Bucket Lifting System
Garbage Compact Ratio	1/3 – 1/4
Control System	There are two control panels on the back and one control panel in the cab
Dispensing System	Equipped with air-tight dustbin, hydraulic system and operating system.
	Automatic loading, compressing and discharging, all handled by 1 person
	Sewage water collection tank to avoid any pollution during handling.
	Large Pressure, Good Leakage Proof, Convenient Operation
	Electrical Control Panel for compacting system.
	Cycling time<14~18s

Paint appearance	Color is optional
	Customized LOGO painting as per customer request
