| Basic Information | Drive Type | 6×4 (4WD on Rear Axle) |
| Wheelbase | 3825 + 1350 mm | |
| Overall Dimensions (L×W×H) | 7490 × 2500 × 3850 mm | |
| Curb Weight | 8805 kg | |
| Gross Vehicle Weight (GVW) | 25000 kg | |
| Maximum Towing Weight | 40000 kg | |
| Minimum Ground Clearance | 250 mm | |
| Engine Parameters | Engine Model | Foton Cummins X12NS6B460 |
| Engine Type | Inline 6-Cylinder, 4-Stroke, Direct Injection, Turbocharged & Intercooled | |
| Displacement | 11.8 L | |
| Fuel Type | Diesel | |
| Maximum Power | 460 HP (338 kW) @ 1900 rpm | |
| Maximum Torque | 2300 N·m @ 1100 – 1500 rpm | |
| Emission Standard | China National VI | |
| Transmission System | Transmission Model | ZF 12TX2421TD |
| Transmission Type | Automated Mechanical Transmission (AMT) | |
| Forward Gears | 12 Gears | |
| Reverse Gears | 2 Gears | |
| Chassis Parameters | Front Axle Load Capacity | 7000 kg |
| Rear Axle Configuration | 400 Series Axle, Dual Rear Axle Group | |
| Rear Axle Load Capacity | 18000 kg | |
| Rear Axle Ratio | 2.846 | |
| Suspension System | Front: 3-Leaf Steel Spring; Rear: Air Suspension | |
| Tire Specification | 12R22.5 | |
| Fuel Tank Capacity | 1000 L (Optional 1350 L) | |
| Cab & Comfort | Cab Type | High-Top Extended Cab |
| Driver Seat | Air-Suspension Seat (Shock Absorption) | |
| Seating Capacity | Half-Row Seating | |
| Key Configurations | Automatic Air Conditioning, Power Windows, Central Locking, ABS + EBD | |
| Performance Parameters | Maximum Speed | 80 km/h |
| Climbing Capacity | ≥ 20% | |
| Stability & Safety | Equipped with ABS + EBD for enhanced braking performance |
