| Overall dimension | 5800*2330*2480mmmm | |
| Laoding weight | 5000kg | |
| Chassis brand | I-SUZU NPR | |
| Traction type | 4*2, left orRight hand drive | |
| Chassis description | ||
| Cab | flat roof,AC | |
| Wheelbase | 3360mm | |
| Tire specification | 7.00R16 | |
| Tire quantity | 6+1units | |
| Engine | Engine model | 4KH1CN6LB |
| Emission level | Euro 5 ( 2 3 4 5 optional) | |
| Displacement/output | 3.0L/88kw | |
| Horse power | 120hp | |
| Brake system | Type | Drum |
| Service brake | Dual-circuit compressed air brake | |
| Park brake | Power spring brake acting on rear wheel | |
| Auxiliary brake | Exhaust brake | |
| Gear box | Model | MSB 5 |
| Number of gears | 5 forward gears&1reverse | |
| Suspension | Front | Leaf spring |
| Rear | Leaf spring | |
| Fuel tanker | Type | Steel fuel tank with lockable cap |
| Up-part description | ||
| Cargo dimension | 3800*2100*800mm | |
| Loading capacity | 5T | |
| Material | Carbon steel | |
| Thickness | Side | 3mm |
| Bottom | 4mm | |
| Hydraulic system | Chinese brand | |
| Lifting style | Middle lifting,Double-cylinder 110 | |
Dump Truck
ISUZU
ISUZU 4X2 Dump Truck
Model: ELF
Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.
Brand
ISUZU
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
