General information

Chassis model

VC66 6X4 Tractor

Wheelbase(mm)

3385+1370

Drive Type

6X4

GVW (kg)

25000

Curb Weight (kg)

8870

Front axle load (kg)

7000

Rear axle load (kg)

18000

Acceptable quasi-trailer gross mass (tons)

Cabin

1.5 row (with sleeper)

Roof

High roof

Driver and Passenger

Engine

Model

6WG1-TCG62

Type

6 Cylinders in line,

high presure, electrical common-rail diesel fuel injection system,

water cooling , turbo charging, inter cooling.

Emission Standard

Euro IV, without Urea

Displacement (L)

15.681

Rated Power (hp/kw)

520HP/382KW

Rated speed (rpm)

1800rpm

Max. Torque (N.m)

2250N.m

Maximum torque speed (rpm)

900-1300rpm

Transmission

Model

ZF 16S

16 Forward + 2 Reverse

Brake System

Service brake

front and rear drum brake

Brake(Air/Oil)

Air brake

Parking brake

Air cut brake valve

Max. Speed (km/h)

110

standard Configuration

Tires

295/80R22.5 18PR

Power steering

Yes

Radio

Yes

A/C

Yes

Tilted cabin

Yes

Exhuast brake

Yes

Central lock

Yes

Electric window

Yes

Optional Configuration

Retarder

Yes

Air suspension

Yes

Chrome grille

Yes

800-litre fuel tank

Yes

Dimensions

Length OAL(mm)

6895

WidthOW (mm)

2540

Height OH (mm)

3970

Front Overhang FOH (mm)

1370

Rear OverhangROH(mm)

770

Front Tread AW (mm)

2065

Rear Tread CW(mm)

1875/1875

Tractor Head ISUZU

ISUZU 6X4 Truck Tractor

Model: GIGA

A truck tractor is a powerful motor vehicle designed to pull heavy trailers, commonly used in freight transportation. It provides the engine and driver’s cabin, while the attached trailer carries the cargo. Truck tractors are essential in long-distance logistics due to their strength, efficiency, and ability to handle large loads.

Brand

ISUZU

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
