Description	JH30-M	JH38-RZ	JH48-XR	JH58-XR
Max.theoretical output	m3/h	90	140	180
Max.concrete outlet pressureItem	MPa	10.5	8.3	8.3
Rated working pressure	MPa	32	32	32
Hydraulic system	/	Open circuit	Open circuit	Open circuit
Pumping frequency	min-1	26	29	29
Concrete cylinder dia x stroke	mm	230X1450	230X1650	260X2100
Rotating angle of turret	•	±360	±360	±360
Max.concrete placing (height/radius/depth)	/	30/26/18.3	38/33/21.2	48/42/29.3
Chassis Model	/	FAW/SINOTRUK
Max.power	HP	180~340		300~420
Emission standards		EURO 5/EURO 6

Concrete Pump Truck JIUHE

JIUHE Concrete Pump Truck

Model: JH30-M

A concrete pump truck is a specialized construction vehicle used to transport and pump liquid concrete to construction sites through a hydraulic pumping system. It is widely used for high-rise buildings, bridges, tunnels, and large construction projects where precise and efficient concrete placement is required.

Brand

JIUHE

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC

Share this product
