| Model | UNIT | TT904 | TT1004 | TT1104 | |||
| DIMENSIONS | TYPE | / | DRIVE TYPE(4 x 4) | ||||
| OF TRACTOR | |||||||
| KW | kw | 66.2 | 74 | 81 | |||
| DIMENSION(L x W x H) | mm | 4485*2100*3060 | |||||
| WHEEL BASE | mm | 2385 | |||||
| MIN.GROUND CLEARANCE | MM | 420 | |||||
| MIN OPERATING TING MASS | kg | 4560 | |||||
| TREAD | mm | FRONT TREAD: 1620(1620~1820)ADJUSTABLE | |||||
| REAR TREAD: | |||||||
| 1620(1620~1820)ADJUSTABLE | |||||||
| MATCHED POWER | CLUTCH TYPE | / | DRY-TYPE,DOUBLE-ACTING | ||||
| ENGINE | / | 4 CYLINDER | |||||
| RATED SPEED | r/min | 2300 | |||||
| WORKING PART | GEAR | / | 16F+8R | ||||
| PTO TYPE | / | 8 SPLINE | |||||
| PTO RATED POWDER | kw | ≥56.3 | ≥63 | ≥69 | |||
| PTO SPEED | r/min | 720/1000 760/850 540/1000 | |||||
| HYDRAULIC SYSTEM | THREE POINT MOUNTING | / | REAR, THREE-POINT SUSPENSION, CAT2 | ||||
| HYDRAULIC OUTPUT | / | 3-WAY VALVE | |||||
| HYDRAULIC ADJUSTMENT MODE | / | FORCE HYDRAULIC SYSTEM, POSITION CONTROL, FLOATING CONTROL | |||||
| MAX.LIFTING FORCE AT FRAME CENTER | kn | ≥15.9 | ≥20.2 | ≥20.7 | |||
| TIRE | STANDARD TYRE SIZE (FRONT/REAR) | / | 12.4-24/16.9-34 | ||||
| OPTIONAL TYPE(I) | / | 13.6-24/16.9-38 | |||||
| OPTIONS | A/C CABIN | / | OPTIONAL | ||||
| HEATED CABIN | OPTIONAL | ||||||
| ROPS,SUNROOF | OPTIONAL | ||||||
Agricultrual Equipment
HARMAC
100HP Farm Tractor
Model: TT1004
A farm tractor is a powerful vehicle designed for agricultural tasks, primarily used to tow or push farming equipment and machinery. Tractors are essential for various farming operations, such as plowing, tilling, planting, harvesting, and transporting materials.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
