Max. lifting capacity × radius			t × m	80×4
Max. lifting capacity on fixed jib			t	7
Max. lifting capacity of luffing jib			t	15
Main boom length			m	13 – 58
Max. length of main boom with fixed jib			m	49+18
Luffing jib length			m	16m-34m
Max. main boom +max. luffing jib			m	43.5m+34m
Derricking angle			.	30 – 80
Fixed jib angle			.	10, 30
Max. rope speed		Hoisting winch 1	m/min	125/110
of winches		Hoisting winch 2		125
		Derricking winch		93
Slewing speed			rpm	0-2
Traveling speed			km/h	0-1.57
Max. gradeability			%	30
Ground pressure			Mpa	0.083
Deadweight			t	72.8
Crane counterweight			t	27
Overall dimensions(L × W × H)			m	13500×5000 (3400) ×3200
Engine		Model		WP10.270N
		Rated power / rotational speed	kW/r/min	199/1900
		Max. output torque /rotational speed	Nm/r/min	1270/1200-1500
		Exhaust emission		National Stage
Distance between track center × crawler contact length × crawler width			mm	2600 ×5440×800
				4200 ×5440×800
Noise	Noise level outside operator’s cab during operation		(dB)	≤107
	Noise level in operator’s cab during operation			≤79

Crawler Crane Zoomlion

15 Ton Crawler Crane

Model: ZCC850H

A Crawler crane is a heavy-duty lifting machine mounted on crawler tracks, designed for handling large loads in demanding construction and industrial environments. Its tracked undercarriage provides excellent stability and weight distribution, allowing operation on soft, uneven, or rugged ground without the need for additional support.

Brand

Zoomlion

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
