| Chassis | Dongfeng Dorica D5 | Top | KTC5L5 | |
| Total weight (KG) | 4495KG | Maximum lifting weight (KG) | 5000KG | |
| curb weight (KG) | 4365KG | Coil | 5T | |
| Engine | Q23-132E60 132HP | boom | 20.3м | |
| Gearbox | Wanliyang | Maximum operating height | 21.5м | |
| Overall dimension | 5995mm*2090mm*2650mm | rotary structure | 360 degree arbitrary rotation | |
| Wheelbase | 2950mm | Big frame | Anti-torsion frame | |
| Tyre model | 6. 50R16LT 1OPR | power pump | Single pump | |
| Front axle/rear axle | 1.6T/3T | Leg | 4 double-section legs | |
| Brake form | Break-off brake | Leg longitudinal/transverse span (mm) | 3300/5000 |
Lifting Equipment
Dongfeng
5 Ton Truck Mounted Crane
Model: KTC5L5D
A Truck Mounted Crane is a lifting machine installed on a truck chassis, combining transportation and lifting capabilities in one efficient unit. It is designed for loading, unloading, and transporting heavy materials while providing flexible lifting operations at different job sites.
Brand
Dongfeng
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
