Performance	Parameter model
Engine	Engine model	cum 6CTA8.3-C215
	Engine rated output	160KW/2200r/min	215h.p./2200r/min
	oil consumption	230 g/kWh
Maximum rated lifting capacity		25000kg	55116pounds
Maximum lifting torque	Base boom	735KN.M(245KN.M*3M)	542341 pound ft
			(55116 pounds * 9.84 ft)
	Fully extended boom	450KN.M(50KN*9m)	332153 pound ft
			(11248 pounds * 29.53 ft)
Maximum lifting height	Base boom	9.8m	32.15ft
	Fully extended boom	27.4m	89.9ft
Base boom length		9.5m	31.17ft
Fully extended boom length		27.8m	91.21ft
Maximum lifting speed of the hook		10.2m/min	33.46ft/min
		(Eight section line)	(Eight section line)
		13.6m/min	44.62ft/min
		(Six section line)	(Six section line)Chain rail section distance
work environment		20	-4oF-104oF
Chain rail section distance		203.2mm	8.0inches
Track shoe width		1100mm (950mm) triangle
		1100mm 43.3 inches (optional track 950mm 37.40 inches)
Minimum ground clearance section		480mm	18.9inches
Level ability		≥20
ground pressure		32kpa	4.64PSI

Crawler Crane HARMAC

28 Meters Crawler Crane

Model: XGCC-25T

A Crawler crane is a heavy-duty lifting machine mounted on crawler tracks, designed for handling large loads in demanding construction and industrial environments. Its tracked undercarriage provides excellent stability and weight distribution, allowing operation on soft, uneven, or rugged ground without the need for additional support.

Brand

HARMAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
