| Main Technical Data of TH1504-3 Tractor | ||
| Tractor parameters | Model NO | TH1504-3 |
| Type | 4 x 4 wheeled drive | |
| L x W x H(mm) | 5023 X 2331 X 2900(up to steering top) | |
| Wheel base(mm) | 2324 | |
| Front wheel tread(mm) | 1830/1930(step adjustable) | |
| Rear wheel tread(mm) | 1630/1830(stepless adjustable) | |
| Min ground clearance | 470mm | |
| Dry mass(kg) | 4413 | |
| Clutch | 14”clutch,Dry type double action constantly connecting | |
| Steering | hydraulic steering | |
| Transmission box | 16F +8 R Shifts | |
| Cabin | Luxury cabin with heater & fan | |
| Engine data | Engine brand | WEICHAI |
| Engine model | WP6G150E330 | |
| Engine type | Inline,cooled water,four stroke,pressurization | |
| Engine Rated power | 110.3kw | |
| Engine Rated speed | 2200(r/min) | |
| Fuel | diesel | |
| Tyre | Front Tyre | 13.6-24 flat tyre |
| Rear Tyre | 16.9-38 flat tyre | |
| PTO | Suspension type | Rear position,rear three point suspension category |
| Hydraulic outlet | three pairs | |
| Pto speed | 760/850 r/min | |
| Pto shift & spline size | 38 spline 8 teeth | |
| Lifting force(N) | 26472 | |
Agricultrual Equipment
HARMAC
150HP Farm Tractor
Model: TH1504
A farm tractor is a powerful vehicle designed for agricultural tasks, primarily used to tow or push farming equipment and machinery. Tractors are essential for various farming operations, such as plowing, tilling, planting, harvesting, and transporting materials.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
