| SPECIFICATIONS | TC1504 | TC1604 | TC1804 | TC2004 | TC2204 |
| Engine Model | YTO | YTO | YUCHAI | YUCHAI | YUCHAI |
| Type | 6-Cylinder | ||||
| Overall Dimensions | 5260/5350*2385*3050 | ||||
| L*W*H(mm) | |||||
| Wheel Bass(mm) | 2770 | ||||
| Min Groud Clearance(mm) | 475 | ||||
| Construction Mass(kg) | 7060 | ||||
| Rated Power(kw/hp) | 110.3/150 | 117.6/160 | 132.4/180 | 147/200 | 161.8/220 |
| Rated Speed(rpm) | 2200 | ||||
| Tyre | 14.9-28/18.4-38,16.9-28/20.8-38,420/85R28+520/85R38,540/65R28,650/65R38 | ||||
| Gear box | 16+8/24+8 | ||||
| 3-Point Suspension | Category:III | ||||
| Rotating Speed(rpm) | 760/850 or 540/1000 | ||||
| Spline Size | 6-35Rectangular Spline or 8-38Rectangular Spline | ||||
| Clutch | 14 inch double action | ||||
| Fuel tank capacity(L) | 640 | ||||
| Hydraulic output flow(L/min) | 79.2 or 92.4 | ||||
Agricultrual Equipment
HARMAC
220HP Farm Tractor
Model: TC2204
A farm tractor is a powerful vehicle designed for agricultural tasks, primarily used to tow or push farming equipment and machinery. Tractors are essential for various farming operations, such as plowing, tilling, planting, harvesting, and transporting materials.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
