	Model					LTR250
	Fuel type					diesel oil
	Rated capacity				kg	20000
	Load center				mm	800
Dimensions	Lift height				mm	3000
	Free lift height				mm	100
	Fork size				mm	2400×200×100
	Shelf Side Shift Distance		Left / Right		mm	205/205
	Fork spacing adjustment		Min./Max.		mm	280/2320
	Mast tilt angle		Before / After		deg	8*10
	Front overhang				mm	1380
	Overall dismensions	Length to face of fork			mm	9700
		Overall width			mm	3040
		Mast lowered height			mm	3350
		Mast extended height			mm	4850
		Safety rack height			mm	3700
	Turning radius				mm	7800
	Min.right angle aisle width				mm	8500
Performance	no load/full load	Travel speed			Km/h	30/28
		Lifting speed			mm/sec	320/270
	Max.grade ability				º	≥21
	Max.Pull force(full load)				KN	180
	Self weight				kg	26000
Chassis	Tyres	Front				2×23.5-25-32PR
		Rear				2×23.5-25-24PR
	Tread	Front			mm	2380
		Rear			mm	2380
	Wheelbase				mm	3710
	Min.Ground clearance(no load/full load)			Mast	mm	450/400
				Frame	mm	500/450
Power Unit and Control	Battery				V/AH	24/100×2
	Engine	Model				6CTA8.3-C240
		Manufacture				Cummins
		Rated output			Kw/rpm	179/2200
		Rated torque			N.m/rpm	1028/1500
		Fuel tank capacity			L	220
	Transmissions	Type				Hydraulic
		Shift		Front/rear		2*1

Forklift HARMAC

25 Ton Rough Terrain Forklift

Model: LTR250

A Rough Terrain forklift is a heavy-duty lifting machine specifically designed to operate on uneven, muddy, sandy, or rugged outdoor surfaces. Equipped with large pneumatic tires, high ground clearance, and powerful engines, it delivers strong traction and stability in challenging working environments.

Brand

HARMAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
