| Maximum Rated Total Lifting Capacity | kg | 25000 |
| Maximum Lifting Moment (Basic Boom) | kN.m | 1142 |
| Maximum Lifting Moment (Long Main Boom) | kN.m | 768 |
| Maximum Lifting Height (Basic Boom) | m | 113 |
| Maximum Lifting Height (Main Boom) | m | 42.1 |
| Maximum Lifting Height (Jib) | m | 50 |
| Maximum Single-Rope Speed (Main Winch) | m/min | 135 |
| Maximum Single-Rope Speed (Auxiliary Winch) | m/min | 120 |
| Boom Telescoping Time | s | 35 |
| Boom Lifting Time | s | 80 |
| Slewing Speed | r/min | 0~2.7 |
| Maximum Operating Altitude | m | 2000 |
| Maximum Travel Speed | km/h | 90 |
| Maximum Climbing Gradient | % | 45 |
| Minimum Turning Diameter | m | 21 |
| Minimum Ground Clearance | mm | 260 |
| Fuel Consumption per 100km | L | 29 |
| Self-weight in Travel State (Total Mass) | kg | 33240 |
| Vehicle Curb Weight | kg | 33045 |
| Front Axle Load | kg | 7240 |
| Rear Axle Load | kg | 26000 |
| Overall Dimensions (Length*Width*Height) | mm | 12870*2550*3520 |
| Outrigger Longitudinal Distance | m | 5.39 |
| Outrigger Lateral Distance | m | 6.3 |
| Tail Swing Radius | mm | 3260 |
| Main Boom Length | m | 10.7~42 |
| Main Boom Lifting Angle | ° | -2~80 |
| Jib Length | m | 80 |
| Jib Installation Angle | ° | 0 15 30 |
Lifting Equipment
Zoomlion
25 Ton Truck Mounted Crane
Model: ZTC250A5-3
A Truck Mounted Crane is a lifting machine installed on a truck chassis, combining transportation and lifting capabilities in one efficient unit. It is designed for loading, unloading, and transporting heavy materials while providing flexible lifting operations at different job sites.
Brand
Zoomlion
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
