25 tons heavy duty Hook Lift Garbage Truck

Product Name	25 tons heavy duty Hook Lift Garbage Truck
Model	CLW5255ZXXBHJ
Chassis Brand	SHACMAN L3000/M3000
Driving Type	6*4 LHD
Gross Weight	25000kg
Related Loading Mass	13670kg
Curb Weight	11200kg
Dimension	842525503250mm
Wheelbase	4375+1350(mm)
Front Axle Loading Capacity	7000kg
Rear Axle Loading Capacity	18000kg
Approach angle	20°
Departure angle	13°
Front Suspension	1130mm
Rear Suspension	2140mm
Tire	11.00R20,10+1 PCS
Max Speed	100 (Km/h)
Engine parameters:
Model
Horse Power	199hp
Displacement	3900cc
Emission Standard	Euro IV
Type	4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling)
Superstructure Parameter:
Tank Volume	25m3/28m3
Tank Shape	Arc-shape
Tank Material thickness	Bottom:3mm Side:3mm
Tank Material	T420(Special Steel)
Compression Ratio	≥2.5
The effective volume of the bucket	≥0.8m³
Loading cycle time	≤40 s
unload garbage time	≤45s
control method	Automatic,Manual
Maximum pressure of hydraulic system	20MPa
Control System	Siemens PLC
Engine power control	Fully automatic control
Tumbler mechanism	240L Garbage bin(Others Optional)

Hook Lift Truck HARMAC

25 tons heavy duty Hook Lift Garbage Truck

Model: HMK6932LUOC62

The Hook Lift Truck is designed for fast and efficient container handling. It provides flexible operation, high payload capacity, and is widely used in waste collection, construction, and logistics.

Brand

HARMAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
