| 2 Axles | 3 Axles | 4 Axles |
| Brand: Vehicle Master | Brand: Vehicle Master | Brand: Vehicle Master |
| Loading Capacity: 30-60T | Loading Capacity: 30-80T | Loading Capacity: 40-100T |
| Gooseneck Type: Optional | Gooseneck Type: Optional | Gooseneck Type: Optional |
| Main Beam | ||
| Material: Q345/T700 | Main Beam Material: Q345/T700 | Main Beam Material: Q345/T700 |
| Upper Plate Thickness: 12mm | Upper Plate Thickness: 16mm | Upper Plate Thickness: 18mm |
| Middle Plate Thickness: 6mm | Middle Plate Thickness: 10mm | Middle Plate Thickness: 12mm |
| Lower Plate Thickness: 14mm | Lower Plate Thickness: 18mm | Lower Plate Thickness: 20mm |
| Main Beam Height: 500mm | Main Beam Height: 500mm | Main Beam Height: 500mm |
| Product Size | ||
| L*W: 13000mm*2550mm | L*W: 13000mm*2550mm | L*W: 13000mm*2550mm |
| Side Wall Height: 600mm-1700mm | Side Wall Height: 600mm-1700mm | Side Wall Height: 600mm-1700mm |
| Axle | ||
| 2 Axles *13 Ton | 3 Axles *13/16 Ton | 4 Axles *13/16 Ton |
| VEHICLE MASTER/FUWA/BPW/Other | VEHICLE MASTER/FUWA/BPW/Other | VEHICLE MASTER/FUWA/BPW/Other |
| Tire | ||
| 12R22.5 (8 Pieces) | 12R22.5 (12 Pieces) | 12R22.5 (16 Pieces) |
| Linglong/Triangle/Double-Coin/ Other Brand | Linglong/Triangle/Double Coin/ Other Brand | Linglong/Triangle/Double-Coin/ Other Brand |
| Rim | ||
| 9.00*22.5 (8 Pieces) Steel/Aluminum | 9.0*22.5 (12 Pieces) Steel/Aluminum | 9.00*22.5 (16 Pieces) Steel/Aluminum |
| Leaf Spring | ||
| 90mm*13mm*10/90mm*16mm*10Pcs | 90mm*13mm*10/90mm*16mm*10Pcs | 90mm*13mm*10/90mm*16mm*10Pcs |
| King Pin | ||
| #50(2″)/#90(3.5″), JOST/Other Brand | #50(2″)/#90(3.5″), JOST/Other Brand | #50(2″)/#90(3.5″), JOST/Other Brand |
| Landing Gear | ||
| 28 Tons Two Speed | 28 Tons Two Speed | 28 Tons Two Speed |
| JOST/Other Brand | JOST/Other Brand | JOST/Other Brand |
| Vehicle Painting | ||
| Electrophoresis painting | Electrophoresis painting | Electrophoresis painting |
Trailer
HARMAC
3 Axle Side Wall Semi Trailer
Model: 50TON
A trailer is a non-powered vehicle designed to be towed by a truck or tractor. It is used to carry goods, equipment, or materials and comes in various types depending on the cargo. Trailers are essential in transportation for moving large or heavy loads efficiently.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
