| Model | GP 404A | GP 454A | GP 504A | |||
| Type | 4×4Wheeled Type,4WD | |||||
| Length | 3250 | 3350 | ||||
| (mm) | Width | 1250 | 1300 | |||
| Dimensions | Height | 1260 | 2000 | |||
| Tread | Front Wheel | 960 | ||||
| of Tractor | Rear Wheel | 900-1020 | ||||
| Wheel Base | 1725 | 1840 | ||||
| Min.Ground clearance | 210(the bottom of transfer case) | |||||
| (kg) | 1440 | 1840 | ||||
| Min.operational Mass | ||||||
| Engine | Model | KM490BT1 | M490T5 | KM4100BT | ||
| Type | Vertical,water cooled and 4-stroke | |||||
| (kw) | 29.4 | 33.1 | 36.8 | |||
| Rated Power | ||||||
| (r/min) | 2400 | 2300 | ||||
| Rated Rev. | ||||||
| Fuel | Diesel | |||||
| Tire | Front Wheel | 7.00-12(6.00-12,6.00-16,5.00-12Optional) | ||||
| Rear Wheel | 13.6-16(9.50-20,9.50-24,9.50-16, | |||||
| 7.50-20,11.2-24Optional) | ||||||
| Clutch | ,, | |||||
| dry-friction,single disc and constant engagement | ||||||
| Steering | Hydraulic Power Steering | |||||
| Transmission Box | 2(4+1)×2((4+4)×2(4+1)×2×2) | |||||
| two shafts,(4+1)×2 composed | ||||||
| ((4+4)×2 or(4+1)×2×2 Optional) | ||||||
| Hitching Type | 1 | |||||
| Post Positioned 3-point linkage Category I | ||||||
| PTO | (r/min) | ,540/760(540/1000720) | ||||
| Type and Rev. | Rear mounted,semi-independent, | |||||
| 540/760(540/1000 or 720 Optional) | ||||||
| Spline Size | I356 | |||||
| I35 Rectangle Spline with 6 teeth | ||||||
Agricultrual Equipment
HARMAC
40HP Farm Tractor
Model: GP404A
A farm tractor is a powerful vehicle designed for agricultural tasks, primarily used to tow or push farming equipment and machinery. Tractors are essential for various farming operations, such as plowing, tilling, planting, harvesting, and transporting materials.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
