| Model | 9QS – 4500T |
| Form | Self – propelled |
| Header Width | 4450 mm |
| Working Dimensions (Length × Width × Height) | 8160×4650×5870 mm |
| Theoretical Chopping Length | 1st gear: Short 6; Long 82nd gear: Short 11; Long 143rd gear: Short 18; Long 22 |
| Engine Power | 353kW/480ps |
| Rated Engine Speed | 1900r/min |
| Chopping Drum Speed | 1140r/min |
| Cutting Type of Header | Disc – type Cutter |
| Type of Stalk Chopping Mechanism | Drum – type |
| Number of Moving Blades | 20 pieces |
| Harvesting Efficiency | ≥28kg/s |
| Stubble Height | ≤150mm |
| Throwing Angle | ±90 degrees |
| Wheelbase | 2710mm |
| Loss Rate | ≤3% |
| Driving Mode | Hydraulic Drive |
| Brake Type | Disc – type |
| Track of Driving Wheels (Front) | 2400mm |
| Track of Steering Wheels (Rear) | 2110mm |
| Tire Specification of Driving Wheels (Front) | 750/65R26 |
| Tire Specification of Steering Wheels (Rear) | 500/60 – 22.5 |
| Operating Speed | 2 – 10km/h |
Agricultrual Equipment
HARMAC
4500mm Harvester Machine
Model: 9QS-4500T
A harvester is a machine used in agriculture to automate the process of harvesting crops. It is designed to efficiently collect mature crops from the fields, reducing the need for manual labor and increasing productivity.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
