| Model | GR320 | GR530 | GR606 |
| Overall dimension (L x W x H) | 7180*2370*3200mm | 8360*3050*3482mm | 8820*3128*3465mm |
| Bucket capacity | 2.2m³ | 3.0m³ | 5m³ |
| Rated load capacity | 3000KG | 5000KG | 6000KG |
| Overall weight | 10000KG(Added counterweight) | 16500KG | 20400KG |
| Min ground clearance | 350mm | 440mm | 460mm |
| Max dumping height | 2803mm | 3100mm | 3330mm |
| Corresponding dumping distance | 1245mm | 1316mm | 1330mm |
| Min turning radius | 5710mm | 6710mm | 7470mm |
| Wheel track | 1850mm | 2150mm | 2250mm |
| Wheel base | 2830mm | 3200mm | 3250mm |
| Engine model | Weichai Deutz WP6G125E22 | Weichai WD10G220E23 | Weichai WD10G240E21 |
| Power/Speed | 92KW/2200 | 162KW/2000 | 175KW/2200 |
| Emission standard | National II | National II | National II |
| Axle | Yunyu Zl30 | Yunyu Zl50 | Yunyu Zl60 |
| Gear | Front 4 rear 2 | Front 2 rear 1 | Front 3 rear 4 |
| Service brake | Air hydraulic disc brake | Air hydraulic disc brake | Air hydraulic disc brake |
| Parking brake | Hand operated | Hand operated | Hand operated |
| Tire size | 17.5-25PR | 23.5-25-16PR | 23.5-25-20PR |
Earthmoving Equipment
HARMAC
6000KG Wheel Loader
Model: GR606
A Wheel Loader is a powerful and versatile machine used for loading, moving, and handling bulk materials such as sand, soil, and gravel. It offers high efficiency, strong performance, and flexible operation for construction, mining, and agricultural applications.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
