| Item | Unit | LT904 | |
| Drive Type | / | 4×4 | |
| Overall Dimension L×W×H | mm | 4396×4396×2810 | |
| Wheel base | mm | 2195 | |
| Front wheel tread | mm | 1610 | |
| Rear wheel tread | mm | 1620-2020 | |
| Min. ground clearance | mm | 379 | |
| Min. steering radius | Unilateral brake | m | 4.2±0.3 |
| Not unilateral brake | m | 4.9±0.3 | |
| Min. operating weight | KG | 4090 | |
| Gearbox gears number | / | 16F+8R | |
| Speed | Forward | Kw/h | 1.58-33.69 |
| Reverse | Kw/h | 2.41-34.67 | |
| Engine | Model | / | LR4M5-23 |
| Rated power | Kw | 66.2 | |
| Rated speed | r/min | 2300 | |
| Tires spec. | Front tires | / | 11.2-24 |
| Rear tires | / | 16.9-34 | |
| Steering Type | / | Full hydraulic front wheels steering | |
| Max. lifting force | KN | 15.9 | |
| PTO | Type | / | Rear-mounted, Independent type |
| Speed | r/min | 760/1000 or 540/1000 | |
| Power | Kw | 56.3 | |
| Control type of ploughing depth | / | Height control & flotation control | |
| Max. traction force | KN | 21.3 | |
| Front / rear Ballast | KG | 270/470 | |
Agricultrual Equipment
HARMAC
90HP Farm Tractor
Model: LT904
A farm tractor is a powerful vehicle designed for agricultural tasks, primarily used to tow or push farming equipment and machinery. Tractors are essential for various farming operations, such as plowing, tilling, planting, harvesting, and transporting materials.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
