| Drive Type | 6×4 LHD/RHD |
| Cab Type | Short/Long Cabin |
| Equipment | With Air Condition, One or none bed |
| Weight | |
| Kerb mass(kg) | 12800 |
| GVW(kg) | 12800+45000 |
| Dimensions | |
| Max. length(mm) | 9880 |
| Max. width(mm) | 2500 |
| Max. height(mm) | 3630 |
| Front/Rear overhang(chassis) | 1410/1870 |
| Wheel base(mm) | 4750+1450 |
| Track width(mm) | 1995/1808 |
| Body size | |
| Length (mm) | 5600–7000 |
| Width (mm) | 2300 |
| Height (mm) | 1500 |
| Thickness of Steel | Floor 8mm, side 6mm |
| Tipping type | Front tipping |
| Performance | |
| Max. speed (km/h) | 75 |
| Max. gradeability(%) | 30 |
| Approach/Departure angel(°) | 26/32 |
| Engine | |
| Brand | WEICHAI BRAND |
| Model | WP10.or WP12 |
| Power (kw/hp) | 336hp/375hp |
| Max torque (N.M)/rpm | 1450/1400–1600 |
| Displacement (L) | 9.726 |
| Emission Standards | Euro III(optional) |
| Transmission | |
| Brand | FAST |
| Model | 9JS180/12JSD160T |
| Control type | Manual |
| Gear Shift | 9/12-forward & 1/2-reverse speeds |
| Clutch | |
| Type | Single plate,diaphragm spring |
| Diameter (mm) | Φ430 |
| Action | hydraulically operating with air assistance |
| Brakes | |
| Type | Drum |
| Service Brake | With dual-circuit compressed air brake |
| Park Brake | Power spring brake acting on rear wheel |
| Auxiliary Brake | WEVB |
| Steering | ZJ120D/D50/TAS85 |
| Chassis | Ladder structure with parallel straight |
| Dimensions (mm) | 300x90x8+6+8 |
| Suspension | |
| Front | Longitudinal leaf spring |
| Rear | Inverted leaf spring stabilizator suspension |
| Axles | BENZ TECHNOLOGY |
| Front | BENZ TYPE: 7.5 tons |
| Rear | BENZ TYPE: 13tons |
| Ratio | 5.921 |
| Tyre | 12.00R20 radial tire |
| Fuel tank | |
| Tank capacity(L) | 300 |
| Material | Aluminum alloy |
| Electrics | |
| Type | 24V |
| Starter | 5.58kw(24) |
| Generator | 2.0kw(28V 70A) |
| Battery | 2x135Ah |
Dump Truck
BEIBEN
BEIBEN 8X4 Dump Truck
Model: 2638
Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.
Brand
BEIBEN
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
