| Driving license: | A1,A2,B2 | Announcement Model: | DYQ3165D6AC |
| Drive type: | 4X2 | Wheelbase: | 3400mm |
| Motor: | Yuchai YCY30165-60 | Gearbox: | Fast 8JS85F-C |
| Rear axle ratio: | 6.5 | Body length: | 6.3 meters |
| Body width: | 2.4 meters | Vehicle Height: | 2.7 meters |
| Front track: | 1780mm | Rear track: | 1700mm |
| Vehicle weight: | 6.2 tons | Rated load: | 9.87 tons |
| Total mass: | 16.2 tons | Tonnage Class: | Medium card |
| Approach Angle: | 16 degrees | Departure Corner: | 18 degrees |
| Origin: | Shandong | Fuel Type: | diesel fuel |
| Engine parameters | |||
| Engine Model: | Yuchai YCY30165-60 | Engine Brand: | Yuchai |
| Number of cylinders: | 4 cylinders | Fuel Type: | diesel fuel |
| Displacement: | 2.97L | Emission Standards: | National VI |
| Maximum horsepower: | 165 hp | Maximum output power: | 121kW |
| Maximum torque: | 500N·m | Maximum Torque Speed: | 1400-2200rpm |
| Rated speed: | 2800rpm | Engine type: | High Voltage Common Rail + EGR + DOC + DPF + SCR + ASC |
| Container parameters | |||
| Cargo length: | 4 meters | Cargo box width: | 2.2 meters |
| Cargo box height: | 0.8 meters | Cargo box form: | Dump |
| Cab parameters | |||
| Cab: | Row half standard top | Number of passengers: | 2 people |
| Transmission parameters | |||
| Transmission model: | Fast 8JS85F-C | Transmission brand: | Fast Priest |
| Gear Shifting Method: | Manual | Forward gear: | 8 gears |
| Number of reverses: | 2 pcs | ||
| Chassis parameters | |||
| Frame Size: | 800×250×(8+4)mm | Front axle description: | 3.2t shortened bridge |
| Permissible load on the front axle: | 5600kg | Rear axle description: | 153 shortened bridge/10t |
| Permissible load on rear axle: | 10600kg | Ratio: | 6.5 |
| Number of springs: | 9/10+8 | ||
| tyre | |||
| Tire Specifications: | 10.00R20 18PR,9.00R20 16PR | Number of tires: | 6 pcs |
Dump Truck
DAYUN
DAYUN 4X2 Dump Truck
Model: 165
Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.
Brand
DAYUN
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
