| MODEL NO | Model: HJH9035 |
| TYPE | Articulated mobile chassis, self loading, mixing, transporting |
| FUNCTION | concrete, sand, fertilizer compound, wet or dry feed materias mixing and discharging |
| PRODUCTIVITY | Up to 4.5 batches per hour, 15.5 cubic hours |
| drive | 4 x 4 |
| steering | Front steering |
| ENGINE | Yuchai Power Ycd4j22t Foshan 16, diesel, water-cooled, 4 cylinders, 2600 RPM, rated power 85KW |
| SPEED | HIGH SPEED: 0-40KM/H; LOW SPEE:0-25KM/H |
| Gear number | Three forwards, three backwards |
| CAB | Driver’s seat: Widen the luxurious cab of the excavator, front window can be opened, anti-roll, anti-falling object type, double armrest cushion seat |
| TIRE | TIRE: 12R-22.5 steel wire high pressure vacuum tire |
| Spiral blade in tank | Double helix mixing, with the guide screw, so that the mixing material more uniform.Turn the feed left, turn the discharge right |
| mixing tank 270°discharges | The tank rotates horizontally to 270 degrees.There is no dead Angle for discharging around the vehicle |
| TIPPING CHUTE | equipped with two 150CM Removable Chute to increase the length of discharge |
| Bucket: | 0.65 cubic, hydraulic gate |
| Bucket discharge switch | Hydraulic gate, electric control |
| OPERATION HANDLE | ELECTRIC CONTROL BUTTON FOUR-WAY GUIDE HANDLE |
| BRAKE | Use Small Servo pump on independent double circuit, use single wheel 4-piston plus double brake caliper |
| Steering: | Hydraulic articulated steering |
| Power System | 24V |
| Fuel tank Water tank | Fuel tank / Water tank: 1 * 800 litres water tank, 135 litres diesel fuel tank, 135 litres hydraulic fuel tank |
| Water Supply System: | self-priming driven pump, 24V self-timing Centrifugal pump, car washing machine |
| HIGH-PRESSURE WATER PUMP WASH | HIGH-PRESSURE WATER PUMP WASH |
| Weighing system | Electronic weighing system (language optional) |
| weight | 8100kg |
| ALARM LAMP | STANDARD CONFIGURATION |
| RADIO | STANDARD CONFIGURATION |
| Length, width, height / wheelbase / Wheelbase: | 7100mm*2750mm*3300mm*2700mm*2200mm |
| ESCAPE HAMMER | STANDARD CONFIGURATION |
| Astern sound prompt | STANDARD CONFIGURATION |
| Turning radius | 2900 mm |
Concrete Mixer Truck
HARMAC
HARMAC Concrete Mixer Truck
Model: HJH9035
A concrete mixer truck is a vehicle used to transport and mix concrete. It has a rotating drum that keeps the concrete in liquid form during transit and delivers it ready for construction use. It is widely used in building, road, and infrastructure projects.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
