| Driving license: | A2 | Announcement model: | CA4250P66K25T1E6 |
| Drive form: | 6X4 | Wheelbase: | 3450+1350mm |
| engine: | Xichai CA6DM2-46E61 | Gearbox: | FAW Jiefang CA12TAX230M |
| Rear axle speed ratio: | 3.727 | Body length: | 7.315 meters |
| Body width: | 2.55 meters | Body height: | 3.56 meters |
| Front wheelbase: | 2020mm | Rear wheelbase: | 1830/1830mm |
| Vehicle weight: | 8.87 tons | Total mass: | 25 tons |
| Total traction mass: | 40 tons | Maximum speed: | 120km/h |
| Market segments: | Logistics distribution | Origin: | Changchun |
| Tonnage level: | Heavy truck | Remark: | Standard equipment: lane keeping system, LCD instrument, clutch assist, steering assist, antenna shift lever, flexible shaft shift control, brake lining replacement alarm. |
| Version: | Premium version 2.0+ | Fuel type: | diesel fuel |
| Engine parameters | |||
| Engine model: | Xichai CA6DM2-46E61 | Engine brand: | xichai |
| Number of cylinders: | 6 cylinder | Fuel type: | diesel fuel |
| Cylinder arrangement: | inline | Displacement: | 11.05L |
| Emission standards: | Euro 5 | Maximum horsepower: | 430 horsepower |
| Maximum output power: | 341kW | ||
| Cab parameters | |||
| Cab suspension: | Four-point airbag suspension | Allowed number of passengers: | 2 people |
| Number of seats: | row half | Cab lift: | electric |
| Driver’s seat form: | Airbag shock-absorbing seat | ||
| Gearbox parameters | |||
| Gearbox model: | FAW Jiefang CA12TAX230M | Gearbox brand: | FAW Jiefang |
| Shifting method: | Manual | Forward gear: | 12 gears |
| Number of reverse gears: | 2 | ||
| tank | |||
| Fuel tank/gas tank material: | Aluminum alloy | Fuel tank capacity: | 1000L |
| Chassis parameters | |||
| Frame size: | 300×80×8mm | Rear axle description: | 435 punch welding bridge |
| Allowable load on front axle: | 7000kg | Allowable load on rear axle: | 18000(two-axle group)kg |
| Speed ratio: | 3.727 | Number of spring leaves: | 23 |
| clutch: | Φ430 | Saddle: | 50# |
| tire | |||
| Number of tires: | 10 | Tire specifications: | 12R22.5 |
Suction Sewage Truck
Dongfeng 4X2 10000L High-Pressure Cleaning Dredging Vehicles and Suction Trucks for Urban Sewage Systems
