| Product Name | Hook Lift Garbage Truck |
| Kerb Weight (Kg) | 11520 |
| Overall Dimensions (mm) | 8470×2520×3120 |
| Lifting Capacity(Kg) | 20000-25000 |
| Big Arm Structure | Integrated Molding |
| Working Environment Temperature ℃ | -20~45 |
| Operating Mode | Automatic+Manual |
| Dumping Angle of Garbage Bin ° | 70 |
| Garbage Bin Capacity(m³) | 20 |
| Trash Container Thickness mm | 5 Side 6 Bottom |
| Garbage Bin Size(mm) | 6200×2500×1700 |
| Material of Garbage Bin | Q235 Carbon Steel |
| Garbage Bin Coating Process | Baking Varnish |
| Max Person Allowed in the Cab | 3 |
| Maximum Speed (km/h) | 89/110 |
| Chassis Technical Parameters | |
| Chassis Brand | Sinotruk |
| Brake | Air Brake/Oil Brake |
| Fuel Type | Diesel |
| Engine Power kw | 228 |
| Front Axle/Rear Axle (t) | 5/Double 10 |
| Gearbox Model | 10-Speed Manual |
| Number of Axles | 3 |
| Wheelbase (mm) | 4300+1350 |
| Number of Tires | 10 |
| Tire Size | 11.00R20 |
Hook Lift Truck
HOWO
HOWO 6X4 Lifting Garbage Truck
Model: ZX710SYFB29
The Hook Lift Truck is designed for fast and efficient container handling. It provides flexible operation, high payload capacity, and is widely used in waste collection, construction, and logistics.
Brand
HOWO
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
