| Product Name | FAW JH6 6X4 Dump Truck |
| Chassis Model | CA3251P25K15L3T1E5A80 |
| Driving Type | LHD (RHD is optional) |
| Cabin | Model JH6 all steel welded COE design, 1-bed flat roof sleeper, 4-point full floating, coil spring (front) / air spring (rear) with shock absorbers, 50 degree electrically-actuated hydraulic cab tilt system with manual back-up and safety latch, lift-up front service panel, sound and heat insulated, aerodynamic tinted impact-resistant plastic exterior sun visor. |
| Engine | Make:XICHAI |
| Diesel 4-stroke direct injection diesel engine | |
| Engine model:CA6DM2-42, Euro 2, 420 HP | |
| 6-cylinder in-line with water cooling, turbo-charging and intercooling | |
| Displacement:11.05 L | |
| Transmission | 12JSD200TA-B, 12F & 2R |
| Steering | TRW TAS85 integral power steering, adjustable tilt and telescopic column. |
| Rear Axle | FAW φ457 |
| Ratio:4.875 | |
| Propeller Shaft | Double universal joint propeller shaft with gear-shaped coupling flange |
| Chassis | Frame: Ladder type, channel section side rails |
| Front suspension:Parabolic springs with shock absorbers | |
| Rear suspension:Parabolic springs, two “V” rods and four “I” rods | |
| Brake | Service brake: dual circuit compressed air brake |
| Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels | |
| Auxiliary brake: engine exhaust brake | |
| Electrics | Operating voltage: 24 V, negative grounded |
| Starter: 24 V, 5.4 Kw | |
| Alternator: 3-phase, 28 V, 1500 W | |
| Batteries: 2 x 12 V, 165 Ah | |
| Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light | |
| Tyres | 12.00R20, radial tyres with one spare tyre |
| Fuel Tank | 400L |
| Body Dimension | 5600*2300*1500mm,bottom 8mm,side 6mm #180 front lifting cylinder |
| Overall Dimension | 8500*2500*3500mm |
Dump Truck
FAW
FAW 6X4 Dump Truck
Model: JH6
Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.
Brand
FAW
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
