| Product Name | FAW JH6 6X4 Tractor Truck |
| Chassis Model | CA4250P66K2T1A3E |
| Driving Type | LHD (RHD is optional) |
| Cabin | Model JH6 all steel welded COE design, 2-bed high roof sleeper, 4-point full floating, coil spring (front) / air spring (rear) with shock absorbers, 50 degree electrically-actuated hydraulic cab tilt system with manual back-up and safety latch, lift-up front service panel, sound and heat insulated, aerodynamic tinted impact-resistant plastic exterior sun visor. |
| Engine | Make:XICHAI |
| Diesel 4-stroke direct injection diesel engine | |
| Engine model:CA6DM2-42, Euro 2, 420 HP | |
| 6-cylinder in-line with water cooling, turbo-charging and intercooling | |
| Displacement:11.05 L | |
| Transmission | 12JSD200TA-B, 12F & 2R |
| Steering | TRW TAS85 integral power steering, adjustable tilt and telescopic column. |
| Rear Axle | FAW φ457 |
| Ratio:4.875 | |
| Propeller Shaft | Double universal joint propeller shaft with gear-shaped coupling flange |
| Chassis | Frame: Ladder type, channel section side rails |
| Front suspension:Parabolic springs with shock absorbers | |
| Rear suspension:Parabolic springs, two “V” rods and four “I” rods | |
| Brake | Service brake: dual circuit compressed air brake |
| Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels | |
| Auxiliary brake: engine exhaust brake | |
| Electrics | Operating voltage: 24 V, negative grounded |
| Starter: 24 V, 5.4 Kw | |
| Alternator: 3-phase, 28 V, 1500 W | |
| Batteries: 2 x 12 V, 165 Ah | |
| Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light | |
| Tyres | 315/80R22.5, tubeless tyres with one spare tyre |
| Fuel Tank | 500L+500L |
| Fifth Wheel | 90# or 50 # |
| Overall Dimension | 6920*2500*3900mm |
Tractor Head
FAW
FAW 6X4 Truck Tractor
Model: JH6
A truck tractor is a powerful motor vehicle designed to pull heavy trailers, commonly used in freight transportation. It provides the engine and driver’s cabin, while the attached trailer carries the cargo. Truck tractors are essential in long-distance logistics due to their strength, efficiency, and ability to handle large loads.
Brand
FAW
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
