| Drivi+D31+A1:D23+A1+A1:D19 | A1,A2,B2 | Announcement Model: | BJ3259DLPKE-AE |
| Drive type: | 6X4 | Wheelbase: | 4300+1350mm |
| Motor: | Weichai WP12.375E50 | Gearbox: | China National Heavy Duty Truck HW19712 |
| Rear axle ratio: | 5.26 | Body length: | 9.29 meters |
| Body width: | 2.55 meters | Vehicle Height: | 3.58 meters |
| Front track: | 2021mm | Rear track: | 1865/1865mm |
| Vehicle weight: | 12.3 tons | Rated load: | 12.57 tons |
| Total mass: | 25 tons | Tonnage Class: | Heavy trucks |
| Approach Angle: | 18 degrees | Departure Corner: | 16 degrees |
| Origin: | Shandong | Market Segments: | Urban construction muck |
| Remark: | With power take-off | Category: | 9 series |
| Fuel Type: | diesel fuel | ||
| Engine parameters | |||
| Engine Model: | Weichai WP12.375E50 | Engine Brand: | Weichai |
| Number of cylinders: | 6 cylinders | Fuel Type: | diesel fuel |
| Displacement: | 11.596L | Emission Standards: | National V |
| Maximum horsepower: | 375 hp | Maximum output power: | 276kW |
| Maximum torque: | 1800N·m | Maximum Torque Speed: | 1000-1400rpm |
| Rated speed: | 1900rpm | Engine type: | Inline, water-cooled, six-cylinder, electronically controlled high-pressure common rail SCR |
| Container parameters | |||
| Cargo length: | 6.5 meters | Cargo box width: | 2.35 meters |
| Cargo box height: | 1.5 meters | Cargo box form: | Flip-up dump type |
| Cab parameters | |||
| Cab: | GTL Flat Top | Cab width: | 2490mm |
| Transmission parameters | |||
| Transmission model: | China National Heavy Duty Truck HW19712 | Transmission brand: | China National Heavy Duty Truck |
| Forward gear: | 12 gears | Number of reverses: | 2 pcs |
| Chassis parameters | |||
| Front axle description: | 9T | Permissible load on the front axle: | 7000kg |
| Rear axle description: | 16 Mercedes | Permissible load on rear axle: | 18000 (two-axle group) kg |
| Ratio: | 5.26 | Number of springs: | 10\12 |
| tyre | |||
| Tire Specifications: | 12.00R20 | Number of tires: | 10 pcs |
Dump Truck
AUMAN
FOTON AUMAN 6X4 Dump Truck
Model: 375
Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.
Brand
AUMAN
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
