| Outer size | 12200x2500x3600mm | 116002500x3750mm | |
| Loading capacity | 48000L | 42000L | |
| Shape | Square Round | Square Round | |
| Total Volume (m3) | 48m3 +5% | 42m3 +5% | |
| Valid Volume (m3) | 48m3 | 42m3 | |
| 5 compartments (customizable) | 5 compartments (customizable) | ||
| Tank assembly | Front/Rear end plate | Material | Carbon Steel/Aluminum Alloy/ stainless steel |
| Front/Rear end plate | thickness | 7mm | |
| Tank body (with insulating layer) | Material | Carbon Steel/Aluminum Alloy/ stainless steel | |
| Thickness | 6mm | ||
| Compartment | 5 pcs | ||
| Manhole cover | Diameter | 500mm | |
| Material | Aluminum Alloy | ||
| Tank assembly | Number | 5 pcs | |
| Discharging valve | Diameter | 3 inch | |
| Material | Aluminum Alloy | ||
| Number | 5 pcs API valve | ||
| Wave-proof plate thickness | 6mm | ||
| Bottom safety valve | Aluminium 3 inch – 2pcs | ||
| Discharging pipe | Diameter | 3 inch | |
| Type | Rubber hose,2pcs | ||
| Cat walk | Standard | ||
| Running mechanism | Axle | Type | 13T /16T/ 28T/ 32T |
| Rim &Tire | Rim Type | 11.5-22.5 / 90.0-22.5 | |
| Tire Type | 385/65R22.5 / 315/80R22.5 / 12R22.5 | ||
| Air Suspension | Mechanical/Air/Bogie Suspension | ||
| King pin | Type | Bolts type | |
| Diameter | 2 inch / 3.5 inch | ||
| Brake system | Brake valve | WABCO valve | |
| Air tank | 45L air tanks | ||
| Brake chamber | 4 double spring brake chamber | ||
| ABS system | China WABCO 4S/2M | ||
| Landing gear | Brand | JOST | |
| Type | E100 two speed | ||
| Accessories | Spare tire carrier | One pcs | |
| Light | LED light | ||
| Voltage | 24v | ||
| Receptacle | 7 ways(7wire harness)and quick change type | ||
| Tool box | One piece,1000x500x500mm | ||
| Paiting | Polyurethane paint&anti-rust primer&sand blasting | ||
| Color | According to the customer request | ||
Trailer
HARMAC
Fuel Tank Semi Trailer
Model: 48000
A trailer is a non-powered vehicle designed to be towed by a truck or tractor. It is used to carry goods, equipment, or materials and comes in various types depending on the cargo. Trailers are essential in transportation for moving large or heavy loads efficiently.
Brand
HARMAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
