| Product Name | tanker | Product identification | |
| Total mass Kg | 9100 | Fuel tank volume m3 | 5 |
| Rated load capacity Kg | 5000 | External dimensions mm | 5945*2100*2500 |
| curb weight kg | 4100 | Cargo compartment dimensions mm | |
| The number of passengers allowed by the cab personnel | 3 | load capacity utilization coefficient | |
| Approach angle Departure angle | 20*16 | Front suspension Rear suspension mm | 1580*1480 |
| Number of axes | 2 | wheelbase mm | 3300 |
| Axle load Kg | 1115 1575 | Maximum speed km h | 80 |
| Other | Upper configuration: Strictly according to the published volume: 5 cubic meters, Q235B plate, cylinder block 4.2 mm thick, head 5 mm thick, bulkhead 4.2 mm thick, single compartment, two European standard tank ports on the top of the tank, a subsea valve with voice alarm system, equipped with 80*60 high flow special oil pump (pumping in and out), optional high flow tanker and 15 m thick reel and gun, standard pumping in and pumping outlet, optional full set of European standard (bottom mounted oil, oil and gas recovery, spill-proof probe, anti-static wire panel) rear ladder, manual guardrail, tool box, rear bumper, side guardrail. | ||
| The above configuration can be customized according to the needs of use | |||
| [Chassis technical parameters] | |||
| Brand name | Manufacturing enterprises | Liberation | |
| External dimensions mm | Number of tires | 5 | |
| Approach angle. de parture angle | 20*16 | Tire size | 7.00R16 |
| Number of leaf springs | The front wheelbase is mm | 1160 | |
| Fuel type | diesel | The rear wheelbase is mm | 1505 |
| Emission standards | |||
| Engine model | Engine manufacturers | Displacement ml | Power kilowatts |
| WP2.3NQ120E61 | Weichai Power Co., Ltd | 2289 | 88 |
