| Outside Dimensions (L*W*H) | 10000*2500*3450mm | |
| Pay-Load | 80 Ton | |
| Tare Weight | 9,000 kg | |
| Bucket | Floor : 8 mm | |
| Sidewall : 6 mm | ||
| Hydraulic system | 3 Hydraulic Cylinders | |
| ( 1 Main Front Hydraulic Cylinder + 2 Assistant Hydraulic Cylinder ) | ||
| Wheel Base | 8390+1310+1310(mm) | |
| Tires | specification | 12.00R20 |
| No. of tires | 12 | |
| Spare tire carriers | 2 | |
| Axles | Brand | FUWA (BPW optional) |
| No. of axles: | 3 | |
| Axle-load | 25 Ton / Axle | |
| Brakes | Style | Compressed Air Brake |
| Brake chamber | double air chamber | |
| System | Dual line braking system | |
| Main Beam | material | I beam ,Q345B, automatic submerged arc welded |
| specification | Height is 500mm,upper plate is 14mm,lower plate is 16mm,middle is 8mm | |
| Cross Beam material | Q235B | |
| Side beam | Channel steel | |
| Accessory | One tooling box with a set of standard trailer tool | |
| Voltage | 24V | |
| Receptacle | 7 ways (7 wire harness) | |
| Lights | Front corner marker lamp :red ;reflector lamp :white | |
| Side marker :orange | ||
| Rear lamp :red; rear reflector :white; turn single lamp :orange | ||
Dump Truck
HONGYAN
HONGYAN 8X4 Dump Truck
Model: 450
Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.
Brand
HONGYAN
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
