| Item | Unit | XZ450PLUS | |
| Engine | Model | QSB8.3-C260 | |
| Rated power | Kw/r/min | 194/2200 | |
| Thrust-Pull | Max pull/ thrust force | kN | 960 |
| Max pull/ thrust speed | m/min | 40 | |
| Rotation | Torque | N.m | 27000 |
| Max spindle speed | r/min | 135 | |
| Mud pump | Max flow rate | L/min | 600 |
| Max pressure | Mpa | 10 | |
| Pipe | Diameter*Length | mm*m | 4.5 |
| Truck-mounted | Lifting weight | t | 2 |
| Loading capacity | t.m | 4 | |
| Max inclination angle | ° | 20 | |
| Max backreamer diameter | mm | 1200 | |
| Weight | t | 13.5 | |
| Dimension | mm | 8800*2280*2610 | |
Drilling Equipment
XCMG
Horizontal Directional Drilling Machine XZ450Plus
Model: XZ450Plus
Horizontal Directional Drill (HDD) is a trenchless drilling machine used to install underground pipes and cables with minimal surface disruption, widely applied in utility and infrastructure construction.
Brand
XCMG
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
