| Product Name | Hook lifting garbage truck |
| Curb weight (kg) | 11520 |
| Overall Dimensions (mm) | 8470×2520×3120 |
| Lifting Capacity (kg) | 20000-25000 |
| Large arm structure | Integrated molding |
| Operating Ambient Temperature (°C) | -20~45 |
| Mode of operation | Automatic + Manual |
| Dump angle (°) | 70 |
| Bins capacity (m & sup3; ) | 20 |
| Trash Can Thickness (mm) | 5 sides and 6 bottoms |
| Bin Size (mm) | 6200×2500×1700 |
| Material of the bin | Q235 carbon steel |
| Trash can painting process | Paint |
| Maximum passengers allowed | 2 |
| [Chassis technical parameters] | |
| Brand name | Sinotruk |
| brake | Air brakes/oil brakes |
| Fuel type | diesel fuel |
| Engine power (kW) | 228 |
| Front/rear axle (t) | 5/Double 10 |
| Transmission model | 10-speed manual |
| Number of axes | 3 |
| Wheelbase (mm) | 4300+1350 |
| Number of tires | 10 |
| Tire size | 11.00R20 |
Hook Lift Truck
HOWO
HOWO 25-ton 8X4 Mounted Lifting Garbage Truck
Model: ZX609SYFB18
The Hook Lift Truck is designed for fast and efficient container handling. It provides flexible operation, high payload capacity, and is widely used in waste collection, construction, and logistics.
Brand
HOWO
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
