| name | Model, Specifications | Belonging System | Remark |
| car chassis | Sinotruk ZZ1167G4515C1 | chassis | H OWO |
| Engine ( optional) | YC4E160-33 | 1 60 horsepower | |
| wheelbase | 4200 mm | ||
| Asphalt tank capacity | 8 cubic meters | tank | High-quality carbon steel |
| Insulation layer thickness | 50 mm | Rock wool insulation | |
| Stainless steel outer casing | 1mm | 1 thick stainless steel plate | |
| power take-off | Specialized for sprayer trucks | Source of motivation for work | |
| hydraulic pump | CBQ5 5 0-L | Hydraulic system | Tianjin |
| proportional valve | EF RD – G 03-160- 05-31 | Northern Precision Machinery | |
| Asphalt pump motor | 05- 110- BD 40 | Ningbo Hanzhu | |
| Asphalt pump | QGB 680 | Asphalt spraying system | Highly expensive, 680 L/min |
| Number of nozzles | 34 | The control method is: 1 control 1 | |
| hand spray gun | 5-meter hose + handheld spray bar | Corner touch-up spray | |
| burner | G20 (100,000 kcal/hour) | Heating system | Rialto |
| Thermal oil pump | RY32 – 32 -160 | Hebei | |
| Thermal oil pump motor | 380V-2.2KW-2 poles | Lu’an, Anhui | |
| Control system method | Cab touchscreen computer + rear work platform control (backup) | control system | The control system uses Siemens control modules, which offer faster and smoother operation and a lower failure rate. |
| speed sensor | Ni5-G12 | Türke, Germany | |
| Temperature controller | PT100 | Shanghai | |
| dynamo | 7 KW gasoline generator | Power System | Domestic |
