| project | Unit | Value | |
| Max.Theor.output(high pressure) | m3/h | 100 | |
| Max. Theor. concrete output | MPa | 7.3 | |
| Hopper capacity | L | 600 | |
| Filling height | mm | 1400 | |
| Hydraulic system type | Open loop | ||
| Distribution valve | S valve | ||
| Oil cylinder dia.×stroke | mm | φ110×1400 | |
| Concrete cylinder dia. ×stroke | mm | φ230×1400 | |
| Hydraulic oil cooling | Air cooling | ||
| Placing boom | Structure type | 32-5RZ | |
| Placing depth | m | 32 | |
| Horizontal distance | m | 27.1 | |
| Slewing angle | ±360° | ||
| Pipe diameter | mm | 125 | |
| End hose length | mm | 3000 | |
| Min. height of opening placing boom | m | 5.8 | |
| Outriggers span (front×rear×side) | mm | 5950×6270×5350 | |
| Chassis and vehicle | total weight | t | 20 |
| Wheelbase | mm | 4600 | |
| Engine type | Yuchai | ||
| Engine power | kW | 176kw | |
| Oil tank cubage | 300 | ||
| Tail gas exhaust standard | China 6 | ||
| Overall dimensions | mm | 9100×2400×3500 | |
| Oil tank volume | 600 | ||
| Control mode | Manual + remote | ||
Concrete Pump Truck
HOWO
HOWO Concrete Pump Truck
Model: JB5190
A concrete pump truck is a specialized construction vehicle used to transport and pump liquid concrete to construction sites through a hydraulic pumping system. It is widely used for high-rise buildings, bridges, tunnels, and large construction projects where precise and efficient concrete placement is required.
Brand
HOWO
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
