Model	Diameter of the moving cone	avity type	Feed opening sizeClosed edge(mm)	Feed opening sizeopen edge(mm)	Adjustment range of the discharge opening(mm)	Processing capacity(th)	Overall dimensions(mm)	Maximum instaled power(kw)
CSB75	900(3″)	F	83	102	9-12	45-91	2821x1880x2164	100
CSB75	900(3″)	C	159	175	13-38	59-163	2821x1880x2164	100
CSB160	1295(4¼)	F	109	137	13-31	109-181	2800x2342x2668	250
		M	188	210	16-31	132-253
		C	216	241	19-51	172-349
CSB240	1650(5½)	F	188	209	16-38	181-327	3991x2870x3771	320
		M	213	241	22-51	258-417
		C	241	268	25-64	299-635
CSD75	900(3″)	F	13	41	3-13	27-90	2881x1880x2164	75
CSD75	900(3″)	C	33	60	3-16	27-100	2881x1880x2164	75
CSD160	1295(4¼)	F	29	64	3-16	36-163	2800x2342x2668	160
		M	54	89	6-16	82-163
		C	70	105	10-25	109-227
CSD240	1650(5½)	F	35	70	5-13	90-209	3917x2870x3771	240
		M	54	89	6-19	136-281
		C	98	133	10-25	190-336

Impact Crusher HARMAC

Hydraulic Impact Crusher

Model: CSB75

An impact crusher is a type of crushing machine used in the mining, construction, and recycling industries to break down materials like rocks, stones, and ores into smaller, more manageable pieces. It operates by utilizing impact force to crush the material, as opposed to traditional crushers that use compression or friction.

Brand

HARMAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping

Strict QC
