| Product Name | Tanker truck |
| Overall Dimensions (mm) | 6600x2000x2500 |
| Curb weight (kg) | 3850 |
| Loading capacity (kg) | 3335 |
| Total Mass (kg) | 7360 |
| Tank thickness (mm) | 3.9 |
| Fuel tank volume (m & sup3; ) | 30.5 |
| Tank material | carbon steel |
| Compartments | 2-6 According to customer needs |
| Operating Ambient Temperature (°C) | -20~45 |
| Manhole cover | European standard |
| Emergency shutdown of the flap | include |
| Oil and gas recovery valve | Include |
| Anti-overflow alarm device | Include |
| Fuel loading method | Bottom fill |
| Gear oil pump flow rate (m & sup3; /h) | 30 |
| toolbox | As needed |
| [Chassis technical parameters] | |
| Chassis brand | 1suzu |
| Drive form | 4*2 left-hand drive driving Right-hand drive drive optional |
| Steering device | Power steering |
| Wheelbase (mm) | 3600 |
| Engine brand | 4KH1CN6LB |
| Horsepower (kW) | 88 |
| Engine Displacement (ml) | 2999 |
| Engine emission standards | EUR 6 |
| Number of engine cylinders | 4 |
| Fuel type | diesel fuel |
| Gearbox | 5 speed forward 1 reverse |
| Front/Rear Axle (t) | 2.58/4.72 |
| hang | Multi-leaf spring |
| Braking system | Front/rear drum full air brakes |
| Tire specifications | 7.00R16LT 14PR |
| Cab configuration | Single-row cab, air conditioning, radio, MP3 and USB ports, anti-lock braking system |
| Rated voltage | 24V,DC |
| Cab color | White, other colors are optional |
Fuel Tanker Truck
ISUZU
ISUZU 5 CBM 4X2 Fuel Tanker Truck
Model: ISUZU 4X2
A fuel tanker truck is a specialized transport vehicle designed for carrying and delivering liquid fuels such as diesel, gasoline, and petroleum products safely and efficiently. It is widely used in fuel distribution, logistics, mining, and industrial operations.
Brand
ISUZU
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
