| Product name | LHD 4X2 IsuzuGiga 205HP 10-12tonDump Truck |
| Chassis parameters | |
| Drive mode | 4X2 |
| Chassis brand | Isuzu Giga chassis |
| Front passenger | 2\3 |
| Cab | Equipped with the new Isuzu VC61-level cab, air conditioning, power steering, central locking, electric doors and windows, multi-function steering wheel, multi-function LCD instrument, ABS, air brake. Front axle 6.3 tons, rear axle 13 tons -20 tons. |
| Engine | 4HK1-TCG60 Isuzu engine,205hp , diesel type |
| Tyre | 295/80R22.5 18PR, 6pcs with 1 spare |
| Gearbox | 6 forward,1reverse,manual operated |
| Steering wheel | Left hand drive |
| Emission standard | Euro 4/6 Emission |
| Wheelbase(mm | 4500mm |
| Max.Speed(Km/h) | 90 |
| Gross weight(kg) | 18000kg |
| Payload(kg) | 10000-120000kg |
| Air Conditioner | With A/C |
| Up-body parameters | |
| Overall dimension(mm) | 7300x2400x3300mm |
| Box dimension(mm) | 4800x2300x600/800mm |
Dump Truck
JAC
JAC 4X2 Dump Truck
Model: 205
Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.
Brand
JAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
Request a Quote
Get pricing & availability within 24h
