Product name	LHD 4X2 IsuzuGiga 205HP 10-12tonDump Truck
Chassis parameters
Drive mode	4X2
Chassis brand	Isuzu Giga chassis
Front passenger	2\3
Cab	Equipped with the new Isuzu VC61-level cab, air conditioning, power steering, central locking, electric doors and windows, multi-function steering wheel, multi-function LCD instrument, ABS, air brake. Front axle 6.3 tons, rear axle 13 tons -20 tons.
Engine	4HK1-TCG60 Isuzu engine,205hp , diesel type
Tyre	295/80R22.5 18PR, 6pcs with 1 spare
Gearbox	6 forward,1reverse,manual operated
Steering wheel	Left hand drive
Emission standard	Euro 4/6 Emission
Wheelbase(mm	4500mm
Max.Speed(Km/h)	90
Gross weight(kg)	18000kg
Payload(kg)	10000-120000kg
Air Conditioner	With A/C
Up-body parameters
Overall dimension(mm)	7300x2400x3300mm
Box dimension(mm)	4800x2300x600/800mm

Dump Truck JAC

JAC 4X2 Dump Truck

Model: 205

Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.

Brand

JAC

Warranty

3 Years

ISO CE Certified

Worldwide Shipping
