| Driving license: | A1,A2,B2 | Announcement Model: | HFC3251P3K3E32S |
| Drive type: | 6X4 | Wheelbase: | 3200+1350mm |
| Motor: | Yuchai YCS06270-60 | Gearbox: | Fast 10JS90A-B |
| Rear axle ratio: | 6.166 | Body length: | 7.475 meters |
| Body width: | 2.5 meters | Vehicle Height: | 2.99 meters |
| Front track: | 2040mm | Rear track: | 1860/1860mm |
| Vehicle weight: | 10.5 tons | Rated load: | 14.37 tons |
| Total mass: | 25 tons | Tonnage Class: | Heavy trucks |
| Approach Angle: | 15 degrees | Departure Corner: | 15 degrees |
| Origin: | Shandong | Market Segments: | Urban construction muck, engineering transportation |
| Fuel Type: | diesel fuel | ||
| Engine parameters | |||
| Engine Model: | Yuchai YCS06270-60 | Engine Brand: | Yuchai |
| Number of cylinders: | 6 cylinders | Fuel Type: | diesel fuel |
| Displacement: | 6.23L | Emission Standards: | National VI |
| Maximum horsepower: | 270 hp | Maximum output power: | 199kW |
| Maximum torque: | 1050N·m | Maximum Torque Speed: | 1200-1700rpm |
| Rated speed: | 2300rpm | Engine type: | High Voltage Common Rail + EGR + DOC + DPF + SCR + ASC |
| Container parameters | |||
| Cargo length: | 4.8 meters | Cargo box width: | 2.3 meters |
| Cargo box height: | 0.9 meters | Cargo box form: | Flip-up dump type |
| Cab parameters | |||
| Cab: | A5L | Cab width: | 2295mm |
| Number of passengers: | 2 people | ||
| Transmission parameters | |||
| Transmission model: | Fast 10JS90A-B | Transmission brand: | Fast Priest |
| Gear Shifting Method: | Manual | Forward gear: | 10 gears |
| Number of reverses: | 2 pcs | ||
| Chassis parameters | |||
| Permissible load on the front axle: | 7000kg | Permissible load on rear axle: | 18000 (two-axle group) kg |
| Ratio: | 6.166 | Number of springs: | 9\10 |
| Maintenance-free wheel ends: | |||
| tyre | |||
| Tire Specifications: | 12R22.5 18PR | Number of tires: | 10 pcs |
Dump Truck
JAC
JAC 6X4 Dump Truck
Model: 350
Dump Truck is a heavy-duty vehicle used to transport and unload bulk materials such as sand, gravel, soil, and ore. It is equipped with a hydraulic system that lifts the truck bed to discharge materials quickly and efficiently. Dump trucks are widely used in mining, construction, and road projects due to their high load capacity and reliable performance.
Brand
JAC
Warranty
3 Years
ISO CE Certified
Worldwide Shipping
Strict QC
